Small Scale Glucose Test Strip Product Line Solution

一、     Item：Glucose Test Strip Product Line

1.     Glucose test strip structure：

1.1 glucose test strip:

In mostly case, the glucose test strip is composed of substrate, electrodes, insulator, hydrophilic layer, enzyme solution, cover slip. Currently, the test strip product line has been widely used in the world.

1.2 Standard of Process (SOP)

1、Substrate pre-processing
2、Screen Printed Electrodes
3、Printed Insulating layer
4、Immobilization

（last 4 manufacture process can be finished in China for the cost effective）
5、Enzyme loading process
7、drying process
8、hydrophilic layer and cover slip

9、Cutting
10、Quality testing
11、Package

CV curve of our solution：

2.     Glucometer：

Glucometer is used to resolve the electrochemical current, display the glucose concentration, and stored the glucose data; The glucometer consists of the signal amplified circuit, CPU processor, AD/DA converter, LCD displayer etc.

			Signal amplified circuit
	Electrochemical current generated by the test strip
					AD converter
